Description
Choosing a rig equipped with the SMC RDC dust collector significantly reduces airborne dust, improving air quality and protecting operators from silicosis. It also ensures cleaner intake air for the engine and air compressor, extending their service life.
The RDC series is a cartridge-type dust collector developed by integrating advanced domestic and international technologies. It features a high-pressure, high-flow pulse valve system that delivers efficient, pulse-by-pulse filter cleaning. With its compact structure, high purification efficiency, and ease of installation and maintenance, the RDC dust collector is a reliable addition to any down-the-hole drilling rig system.
Technical Details
| Description | |||
|---|---|---|---|
| Model | RDC-140 | RDC-165 | RDC-200 |
| Maximum adaptable aperture(mm) | 152 | 165 | 200 |
| Aspiration pipe diameter（mm) | 152 | 152 | 203 |
| Displacement of hydraulic motor(ml/r) | 10 | 10 | 12 |
| Rated pressure of hydraulic motor(Mpa) | 35 | 35 | 35 |
| Number of filter elements | 16 | 24 | 30 |
| Control power | DC24V | DC24V | DC24V |
