Description
It is used for the solution treatment of titanium alloy in aerospace industry, such as TC4, TC16, TC18, TC21, beryllium bronze in aircraft instrument elastic elements precision alloy in aircraft sensor like Ni-based and Co-based high elastic alloy 3J1, 3J21, Ni-based constant elastic alloy 3J53, stainless steel in the field of nuclear energy like17-4PH, 410.
Technical Details
| Description | |||
|---|---|---|---|
| Model | SMC-HTE-335D | SMC-HTE-446D | SMC-HTE-557D |
| Effective hot zone size W×H×L (mm) | 300×300×500 | 400×400×600 | 500×500×700 |
| Loading capacity (kg) | 75 | 250 | 400 |
| Heating Power (kW) | 48 | 75 | 90 |
| Max. temperature (°C) | 1150 | 1150 | 1150 |
| Temperature Uniformity (°C) | ±5 | ±5 | ±5 |
| Vacuum degree (Pa) | 4×10⁻¹ | 4×10⁻¹ | 4×10⁻¹ |
| 4 × 10⁻³/6 × 10⁻⁴ | 4 × 10⁻³/6 × 10⁻⁴ | 4 × 10⁻³/6 × 10⁻⁴ | |
| Pressure Increasing Rate (Pa/h) | ≤0.26 | ≤0.26 | ≤0.26 |
| ≤0.65 | ≤0.65 | ≤0.65 | |
| Transportation time (S) | ≤12 | ≤15 | ≤20 |
| Water tank (L) | 800 | 2000 | 3500 |
| Purge gas | N2/Ar | N2/Ar | N2/Ar |
| Gas cooling pressure (bar) | 2 | 2 | 2 |
