Description
The Hot Isostatic Press is a high-performance system designed for forming, sintering, and densification of advanced materials such as carbon-based composites, high-performance ceramics, powder metallurgy components, and high-temperature/titanium aluminum alloys. Leveraging ultra-high pressure and temperature, it achieves near-theoretical density and exceptional mechanical properties in finished parts.
This system utilizes uniform isostatic pressure and high-temperature thermal fields to eliminate internal porosity, improve material uniformity, and enhance structural integrity. With flexible chamber dimensions, high-end forging components, and customizable process parameters, it supports demanding applications in aerospace, defense, automotive, and energy sectors.
Technical Details
| Description | |||
|---|---|---|---|
| Model | SMC-HTE-HIP | SMC-HTE-HIP2 | SMC-HTE-HIP3 |
| Working Zone Size (mm) | Φ1250 × 2500 | Φ1250 × 2000 | Φ1250 × 1500 |
| Standard Pressure (MPa) | 30, 50, 80, 100, 120, 150, 200 | 30, 50, 80, 100, 120, 150, 200 | 30, 50, 80, 100, 120, 150, 200 |
| Standard Temperature (°C) | 1000, 1100, 1400, 1500, 2000 | 1000, 1100, 1400, 1500, 2000 | 1000, 1100, 1400, 1500, 2000 |
