Description
The construction pile frame features a 360° rotation capability and operates with low grounding voltage, ensuring safety and efficiency. Known for its high stability, it is considered the most stable construction pile frame available. Its design allows it to be widely used across various applications and to be paired with multiple devices, enhancing its versatility. Additionally, it is extremely cost-effective, offering excellent value without compromising performance. The frame also comes with optional height adjustments to accommodate different types of piles, making it adaptable to diverse construction needs.
Technical Details
| Description | |||
|---|---|---|---|
| Model | Unit | SMC-CE-JB120B | SMC-CE-JB136B |
| Leader Height | m | 25 | 25 |
| Leader guide | mm | 600*φ102 | 600*φ102 |
| Leader inclinations | ° | Forward tilt 2° Back tilt 5° | Forward tilt 2° Back tilt 5° |
| Slope climbing capacity | ° | 2 | 2 |
| Lock lever main winch 1 set | Max stength | 8 | 8 |
| Rolling speed | 0-30 | 0-30 | |
| Rope | 26NAT6*19W+NF1770-165m | 26NAT6*19W+NF1770-165m | |
| Motor power | 37KW-6/650 减速箱 | 37KW-6/650 减速箱 | |
| Aux winch for pile lifting 2 sets | Max stength | 3 | 3 |
| Rolling speed | 0-30 | 0-30 | |
| Wire Rope(pile lifting) | 16NAT6"19W+NF1770-115m | 16NAT6"19W+NF1770-115m | |
| Motor power | 18.5KW-4/400 减速箱 | 18.5KW-4/400 减速箱 | |
| Aux winch for pile lifting 2 sets | Max stength | 3 | 3 |
| Rolling speed | 0-33 | 0-33 | |
| Rope | 18NAT6*19W+NF1770-110m | 18NAT6*19W+NF1770-110m | |
| Motor power | 15KW-6/400 减速箱 | 15KW-6/400 减速箱 | |
| Platform rotating angle | ° | 13 | 13 |
| Aux winch for pile lifting 2 sets | Long bridge cylinder and distance | φ110/φ70-2800 | φ110/φ70-2800 |
| Long bridge step pace | 2800 | 2800 | |
| Short bridge cylinder and distance | φ125/φ70-1000 | φ125/φ70-1000 | |
| Short bridge step pace | 1000 | 1000 | |
| Long bridge loading pressure | 0.028 | 0.028 | |
| Short bridge loading pressure | 0.029 | 0.029 | |
| Screw adjustment range | mm | 0-300 | 0-300 |
| Leg cylinder and stroke | mm | Front φ265/φ160-1100 rear φ225/φ140-1100 | Front φ265/φ160-1100 rear φ225/φ140-1100 |
| Hydraulic system | Motot power (kw) | 30 | 30 |
| Pressure(Mpa) | 25 | 25 | |
| Net weight | t | 58 | 60 |
| Overall size(L*W*H) | m | 13.5*9.1*25.8 | 13.5*9.1*25.8 |
| Transporation | m | 15*3.58*3.93 | 15*3.58*3.93 |
| Applicable Hydraulic pressure Hammer | / | NDY16 and below | NDY20 and below |
