Description
Engineered to meet the toughest demands in mining, quarrying, and large-scale construction, these heavy-duty hydraulic excavators deliver reliable performance, outstanding digging power, and versatile adaptability. Equipped with high-output engines, large-displacement pumps, and intelligent electronic control systems, they ensure maximum efficiency and extended machine life.
Each machine offers a spacious, ergonomic cab with a full-color 10.1-inch capacitive IPS touchscreen, designed for optimal visibility even in bright sunlight. With tool compatibility ranging from rock buckets and breaker hammers to ultra-powerful booms and rippers, these excavators can be tailored to handle diverse terrains and job requirements.
Technical Details
| Description | |||
|---|---|---|---|
| MODEL | SMC-CE-SE650LC | SMC-CE-SE680LCW | SMC-CE-SE750LC |
| Operating weight(kg) | 64500 | 66000 | 72500 |
| Engine power(kW/rpm) | 377/1800 | 566/1900 | 377/1800 |
| Bucket capacity(m³) | 3.6 | 4 | 4.5 |
| External dimensions(mm) | 12245*3735*4750 | 12245*3735*4750 | 11260*4310*4740 |
| Bucket rod digging force(kN) | 365 | 350 | 365 |
| Bucket digging force(kN) | 420 | 420 | 420 |
| Rotating speed(r/min) | 0-7 | 0-7.2 | 0-7 |
| Travel speed(km/h) | 3.2/4.7 | 3.2/4.7 | 3.2/4.7 |
| Maximum digging height(mm) | 10855 | 10855 | 11070 |
| Maximum digging distance(mm) | 11520 | 11520 | 11530 |
| Maximum digging depth(mm) | 7040 | 7040 | 6835 |
| Emissions (Indicated as per international standards) | Eu stage IIIA | Eu stage IIIA | Eu stage IIIA |
