Description
TRADITIONAL PISTONS PUMP TYPE DUPLEX 6×6
– Cylinders body and transmission case made of laminated steel, welded.
– High capacity roller bearing fitted on both crankshaft sides.
– Screwed valve pot covers for quick inspection and replacing of the wearing parts (valves, seats).
– Lubrication of bearings and crossheads.
– Ball valves and valve seats.
– The motion drive is obtained by an orbital hydraulic motor.
Technical Details
| Description | |||
|---|---|---|---|
| Stroke in | 6″ | ||
| oil pressure bar | 200 | ||
| Oil displacement dm³/min | 180 | ||
| Double effect pistons | 2 | ||
| Weight Kg | 700 | ||
| LINER diam | 6″,5″,4 ½”,4″ | ||
| MUD PRESSURE BAR | 23,32,40,51 | ||
| MUD DISPLACEMENT L/MIN | 900,620,510,400 | ||
| Diesel Engine power HP | 100 | ||
| JACK SHAFT STROKE/MIN | 90 |
