Description
The SMC Oil-Free Water-Lubricated Air Compressor features an integrated modular design, eliminating complex piping and wiring systems to reduce failure points and enhance operational stability. Equipped with advanced variable frequency technology, this compressor adapts efficiently to varying working conditions, delivering significant energy savings.
Designed for quiet operation, the unit includes ultra-low noise fans, sound-absorbing materials, and vibration-dampening measures to minimize noise levels. The water-lubricated system provides precise cooling and lubrication, extending the compressor’s lifespan while eliminating the need for oil filtration and condensate treatment equipment.
Overall, the SMC Oil-Free Water-Lubricated Screw Air Compressor is a dependable and efficient solution for industries requiring high-quality compressed air. Its innovative design, safety features, low noise, and ease of maintenance make it a cost-effective choice for demanding industrial applications.
Technical Details
Description | |||
---|---|---|---|
Model | 15WSFe-8 | 22WSFe-8 | 37WSFe-8 |
Electric motor power | 15kW | 22kW | 37kW |
Air discharge capacity FAD | 1.0-2.43m3/min | 1.5-3.7m3/min | 2.6-6.5m3/min |
Rated speed | 3000rpm | 3000rpm | 3000rpm |
Weight | 670kg | 780kg | 1200kg |
Dimensions (L×W×H)mm Air discharge | 1370×850×1290 | 1460×960×1400 | 1700×1085×1600 |
Air discharge valve size | DN20 | DN25 | DN32 |
