Description
Designed for both convenience and comfort, the cab features a large-angle backward flipping mechanism, providing ample access to the maintenance area. The integrated control panel offers intuitive operation and a clear, real-time display of machine performance metrics, allowing operators to monitor working conditions with ease.
Technical Details
| Description | |||
|---|---|---|---|
| MODEL | SMC-CE-SSL55B | SMC-CE-SSL70B | SMC-CE-SSL85B |
| Total power(kw) | 36.7 | 45 | 55 |
| Operating weight(kg) | 2800 | 2900 | 3500 |
| Bucket capacity(m³) | 0.43 | 0.48 | 0.54 |
| External dimensions(mm) | 3320X1530X2000 | 3220X1820X2000 | 3460X1820X2000 |
| Rated loading capacity(t) | 0.75 | 0.85 | 1.2 |
| Maximum dumping height(mm) | 2180 | 2260 | 2440 |
| Dumping distance(mm) | / | / | / |
| Subtotal(s) | / | / | / |
| Wheelbase(mm) | 1050 | 1050 | 1080 |
| Maximum speed(km/h) | 9.3 | 9.5 | 11.8 |
| Emissions (Indicated as per international standards) | Eu stage IIIA | Eu stageⅡ | Eu stageⅡ |
