Description
The Vacuum Oil Quenching Furnace is specifically designed for the vacuum heat treatment of a wide range of materials, including alloy steels, high-speed steels, super high-strength steels, M300 steel, and more. This furnace excels in providing controlled, uniform quenching for parts that require minimal deformation and high structural integrity.
Particularly ideal for processing large or complex components such as long rod parts, plate-type parts, long axle components, and landing gears, the furnace ensures that treated parts maintain superior hardness, strength, and durability. Its precision vacuum quenching process minimizes distortion, delivering consistent results with excellent microstructure properties.
Key Features:
Vacuum Oil Quenching: Ensures minimal deformation and superior hardness.
Material Compatibility: Suitable for a variety of alloys, including high-speed steel, alloy steel, and super high-strength steel.
Large and Complex Parts: Specially designed to accommodate long rods, plates, axles, landing gears, and other large components.
Precision & Consistency: Provides uniform heat treatment and ensures excellent microstructure and mechanical properties.
Reduced Deformation: The vacuum environment minimizes distortion during the quenching process.
With its robust design and precision capabilities, the Vacuum Oil Quenching Furnace is an indispensable solution for industries requiring high-performance, large-scale heat treatment with minimal distortion and optimal structural quality.
Technical Details
| Description | |||
|---|---|---|---|
| SpecModel | SMC-HTE-0812D | SMC-HTE-1015D | SMC-HTE-1218D |
| Effective hot zone size Φ D×H (mm) | Φ800 × 1200 | Φ1000 × 1500 | Φ1200 × 1800 |
| Load capacity of vacuum twin chamber oil quench furnace (kg) | 600 | 1000 | 1200 |
| Heating Power (kW) | 240 | 330 | 450 |
| Max.Temperature(°C) | 1050 | 1050 | 1050 |
| 1350 | 1350 | 1350 | |
| Temperature Uniformity (°C) | ±5 | ±5 | ±5 |
| Vacuum degree (Pa | 4 × 10-1 | 4 × 10-1 | 4 × 10-1 |
| 4 × 10-3/6 × 10-4 | 4 × 10-3/6 × 10-4 | 4 × 10-3/6 × 10-4 | |
| Pressure Increase Rate (Pa/h) | ≤0.26 | ≤0.26 | ≤0.26 |
| ≤0.65 | ≤0.65 | ≤0.65 | |
| Transportation time (S) | ≤20 | ≤36 | ≤45 |
| Oil tank volume (L) | 5000 | 98000 | 11000 |
| Cooling gas (99.995%) | N2/Ar | N2/Ar | N2/Ar |
| Gas cooling pressure (bar) | 2 | 2 | 2 |
