Description
The Vacuum Oil Quenching Furnace is designed for the heat treatment of high-performance materials such as alloy steel, high-speed steel, super high-strength steel, M300 steel, and other advanced alloys. Particularly suitable for vacuum oil quenching of large-size parts, including long rod-type parts, plate-type parts, long axle parts, and landing gears, this furnace provides exceptional results where precision and minimal deformation are essential.
The vacuum oil quenching process ensures that components experience minimal distortion while retaining their structural integrity. By maintaining an optimal temperature and pressure, this furnace produces high-quality results for complex components requiring strength, toughness, and dimensional accuracy.
Key Features:
Vacuum Oil Quenching: Ensures uniform cooling while preventing oxidation and distortion, leading to high-quality mechanical properties.
Ideal for Large Parts: Specifically designed for large, long rod-type parts, plates, and axle components, such as landing gears, which require precise heat treatment without significant deformation.
Minimal Deformation: The controlled vacuum environment results in little deformation and superior structure, making it ideal for large-scale applications that need to meet demanding performance standards.
High-Quality Material Processing: Suitable for alloy steel, high-speed steel, super high-strength steel, and M300 steel, providing enhanced hardness and toughness.
Applications:
Large Structural Parts: Ideal for long rod parts, plate-type components, and long axle parts that require minimal distortion after quenching.
Aerospace Components: Perfect for high-performance landing gears and other critical aerospace parts requiring precise heat treatment.
Heavy-Duty Industrial Components: Suitable for large-scale industrial parts that need to meet high mechanical standards and performance.
This Vacuum Oil Quenching Furnace ensures that treated materials achieve optimum hardness, toughness, and reliable performance with minimal dimensional change—ideal for industries requiring precision in heat treatment of large or complex parts.
Technical Details
| Description | |||
|---|---|---|---|
| SpecModel | SMC-VVOQ-0812D | SMC-VVOQ-1015D | SMC-VVOQ-1218D |
| Effective hot zone size Φ D×H (mm) | Φ800 × 1200 | Φ1000 × 1500 | Φ1200 × 1800 |
| Load capacity of vacuum twin chamber oil quench furnace (kg) | 600 | 1000 | 1200 |
| Heating Power (kW) | 240 | 330 | 450 |
| Max.Temperature(°C) | 1050 | 1050 | 1050 |
| 1350 | 1350 | 1350 | |
| Temperature Uniformity (°C) | ±5 | ±5 | ±5 |
| Vacuum degree (Pa) | 4 × 10-1 | 4 × 10-1 | 4 × 10-1 |
| 4 × 10-3/6 × 10-4 | 4 × 10-3/6 × 10-4 | 4 × 10-3/6 × 10-4 | |
| Pressure Increase Rate (Pa/h) | ≤0.26 | ≤0.26 | ≤0.26 |
| ≤0.65 | ≤0.65 | ≤0.65 | |
| Transportation time (S) | ≤20 | ≤36 | ≤45 |
| Oil tank volume (L) | 5000 | 98000 | 11000 |
| Cooling gas (99.995%) | N2/Ar | N2/Ar | N2/Ar |
| Gas cooling pressure (bar) | 2 | 2 | 2 |
