Description
Vertical vacuum water quenching furnace is applied for the solution of titanium alloy in aerospace industry, such as TC4, TC16, beryllium bronze in aircraft instrument elastic elements. Precision alloy in aircraft sensor like Ni-based and Co-based high elastic alloy 3J1, 3J21, Ni-based constant elastic alloy 3J53, stainless steel in the field of nuclear energy like17-4PH, 410.
Technical Details
| Description | |||
|---|---|---|---|
| Model | SMC-HTE-3030D | SMC-HTE-4040D | SMC-HTE-5050D |
| Effective hot zone size Φ×H (mm) | Φ300 × 300 | Φ400 × 400 | Φ500 × 500 |
| Loading capacity (kg) | 50 | 75 | 120 |
| Heating Power (kW) | 35 | 60 | 75 |
| Max.Temperature(°C) | 1350 | 1350 | 1350 |
| Temperature Uniformity (°C) | ±5 | ±5 | ±5 |
| Vacuum degree (Pa) | 4× 10⁻³/6 × 10⁻⁴ | 4× 10⁻³/6 × 10⁻⁴ | 4× 10⁻³/6 × 10⁻⁴ |
| Pressure Increase Rate (Pa/h) | ≤0.26 | ≤0.26 | ≤0.26 |
| ≤0.65 | ≤0.65 | ≤0.65 | |
| Transportation time (S) | ≤6 | ≤6 | ≤6 |
| Quenching medium | Purified Water | Purified Water | Purified Water |
